Osram QTP-Optimal Vorschaltgerät

DPD

Osram HOMELIGHTING Lampen Vorschaltgerät 0 (2 x )

ECG for FL and CFL - not dimmable. Product benefits: • Long lamp life • No adverse effect from frequent on/off switching • Automatic restart after lamp replacement • Perfect lamp start for applications with motion sensors • VDE/VDE EMC certified system • Very high energy efficiency due to cut-off technology • Areas of application: • Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100, industry, open-plan offices, corridors and storage rooms, public buildings, sports halls and factories, strip lighting • Suitable for emergency lighting (DC operation) • Modernization of existing systems. Product features: • Supply voltage: 220...240 V • Line voltage: 198...264 V • Line frequency: 0 Hz, 50 Hz...60 Hz • Lamp start with optimum filament preheating • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate) • Energy Efficiency Index EEI: A2 BAT • Automatic shutdown of defective lamps and at end of life (EoL T.2) • Safety: to EN 61347-2-3 • Lamp operation: to EN 60929
